Rotel A11 MKII + WiiM Mini
Pack content
Amplifier with DAC
The A11MKII stereo integrated amplifier offers an ideal combination of power and connectivity, starting from a linear power supply with a generous toroidal power transformer manufactured by Rotel.
As a result, it is capable of delivering a robust 50 watts continuous per channel in Class AB over 8 ohms and even more with demanding loudspeakers. Unique innovations in the power supply and critical circuit layout provide physical and electrical separation that reduces background noise and increases musical dynamics, while a multi-tap transformer independently feeds sensitive low-voltage circuitry and the high-current amplifier stage of the output section, isolating the audio signal path from noise and reducing unwanted distortion.
Both analogue and digital sources are welcome, with three RCA line-level inputs, coaxial and optical digital inputs, a moving magnet (MM) cartridge-compatible phono stage and Bluetooth aptX HD. The front panel includes a 1/8" headphone jack with dedicated amplifier circuitry for private listening sessions.
Finally, user-friendly features such as a detachable IEC power cable, two 12 V trigger signal outputs, robust speaker connection terminals and auto start/shutdown functions ensure compatibility with any installation.
Features:
- Integrated amplifier with DAC at an exceptional price/performance ratio.
- Enhanced version of the A11 Tribute, co-developed by Ken Ishiwata.
- Executed with audiophile grade components.
- TI chip-based DAC section with 32-bit/384 kHz technology.
- Phono input for moving magnet (MM) capsules.
- 3 analogue inputs with RCA connectors.
- Coaxial (1) and optical (19) digital inputs.
- Bluetooth support for aptX HD and AAC streaming.
- Dedicated pre-out with RCA connectors.
- Two sets of selectable A/B speaker outputs.
- RS232 port and two outputs for 12 V trigger signal.
- 2 x 50 Watts RMS into 8 ohms or 2 x 62 Watts RMS into 4 ohms.
- Frequency response 10-100,000 Hz, -0.5 dB, +0.05 dB Line.
- Frequency response 20-20,000 Hz, -0.5 dB, +0.3 dB Phono.
- Dimensions: 430 x 73 x 347 mm (W x H x D).
- Weight: 6.8 kg.
Free streamer with free control app WiiM Mini valued at 89€.
Experience the power of seamless streaming with WiiM mini: Your stereo system will noticeably improve. With a very simple initial setup, WiiM Mini will add functionalities such as AirPlay 2 to your sound system, streaming music from iOS/Mac or TV audio from Apple TV. Connect your Apple devices to your favorite audio equipment simply and affordably. Plus, enjoy Chromecast streaming music, TV audio, podcasts, and more from hundreds of apps to multiple audio devices simultaneously.
Experience high resolution and continuous playback: WiiM mini lets you wirelessly stream music up to 24-bit/192kHz on digital and analog outputs. Enjoy your music without interruptions and experience bit-perfect output through digital optical or Coaxial. Although not all services offer 24-bit/192 kHz, Amazon Music Ultra HD, Qobuz, and your library support high resolution. TIDAL Connect users enjoy Tidal Master with MQA or Flac up to 24-bit/96kHz.
Stream directly from your favorite music apps: Stream music directly from Spotify, the Tidal app, or Amazon Music using Spotify Connect, Tidal Connect, or Alexa. Provides superior audio quality and longer range compared to traditional Bluetooth or AirPlay 2 receivers, freeing up your mobile device for other tasks. This feature is compatible with users of Spotify Free/Premium, Tidal HiFi and Master quality (with MQA or Flac) and Amazon Prime Music.
WiiM Mini features a high-precision, ultra-low jitter DAC, and supports up to 192kHz/24-bit audio with an SNR of up to 102dB. With much higher bandwidth and a more reliable connection provided by dual-band Wi-Fi than Bluetooth, WiiM Mini is a true Hi-Res streaming DAC device.
10-band graphic equalizer with twenty-six EQ presets give you several options to meet your specific listening needs. The preset equalizer includes options for music genres, bass/treble adjustment, loudness, movies, games, voice enhancement, etc. You can also customize it to suit your room or your tastes.
Voice Control with Alexa, Google and Siri - WiiM Pro is compatible with Alexa, Google and Siri Voice Assistants. Control your music selection, volume and playback using your voice through your phone, HomePod, Echo or Google Home.
Multi-room properties: With WiiM Mini you can create a network of devices connected to each other through the home Ethernet network or by Wi-Fi through the different rooms of your house and fully control them all from any of them using its free and very simple application. handling and high reliability.
Its physical audio input and output connections, both digital and analog, make it much easier to interact with other players and amplifiers in existing equipment, whether Hi-Fi or Home Cinema.
Characteristics:
- Streamer compatible with high resolution and multiroom capacity.
- Internal DAC with resolution up to 24 bits/192kHz.
- Internet connection via Wi-Fi or Ethernet cable.
- It offers internet services such as Spotify, Amazon Music, Deezer, Tunein, Tidal, Qobuz, SoundCloud, Pandora, iHeartRadio, Napster, Soundmachine, Calm Radio, etc.
- Wireless link via Bluetooth 5.0, Airplay 2, Chromecast Audio or DLNA.
- Supported audio formats: MP3, AAC, ALAC, APE, FLAC, WAV, WMA and OGG.
- Audio inputs: 3.5mm stereo analog minijack.
- Audio outputs: Optical digital (Toslink) and analog stereo 3.5mm minijack.
- Power with USB-C socket.
- Voice Control with Alexa and Siri and capacitive touch.
- Timer function with programmed connection/disconnection.
- 10-band graphic equalization.
- Signal to noise ratio: 102dB.
- Total harmonic distortion: 0.009%.
- Measurements: 69 mm diameter x 24 mm height.
- Weight: 40 grams.
- Includes USB-C cable (without wall plug adapter), RCA to RCA stereo cable, Toslink optical digital audio cable and user guide.
