The A11MKII stereo integrated amplifier offers an ideal combination of power and connectivity, starting from a linear power supply with a generous toroidal power transformer manufactured by Rotel .
Thanks to this, it is capable of delivering a robust 50 continuous watts per channel in Class AB over 8 ohms and even more with demanding speakers. Exclusive innovations in the power supply and critical circuitry layout provide physical and electrical separation that reduces background noise and increases musical dynamics, while a multi-tap transformer independently powers sensitive low-voltage circuitry and the amplification stage. current from the output section, isolating the path traveled by the audio signal from noise and reducing unwanted distortion.
Both analog and digital sources are welcome, with three line-level RCA inputs, coaxial and optical digital inputs, a phono stage compatible with moving magnet (MM) capsules, and Bluetooth aptX HD. A 1/8" headphone jack with dedicated amplifier circuitry is included on the front panel for private listening sessions.
Finally, easy-to-use features such as a removable IEC power cable, two 12V trigger signal outputs, robust speaker connection terminals and automatic start/stop functions ensure compatibility with any installation.
Characteristics:
- Integrated amplifier with DAC with exceptional quality/price ratio.
- Improved version of the A11 Tribute, co-developed by Ken Ishiwata.
- Executed with audiophile grade components.
- DAC section based on a TI “chip” with 32-bit/384 kHz technology.
- Phono input for moving magnet (MM) cartridges.
- 3 analog inputs with RCA connectors.
- Coaxial (1) and optical (19) digital inputs.
- Bluetooth compatible for aptX HD and AAC streaming.
- Dedicated preout with RCA connectors.
- Two sets of selectable A/B speaker outputs.
- RS232 port and two outputs for 12 V trigger signal.
- 2 x 50 watts RMS into 8 ohms or 2 x 62 watts RMS into 4 ohms.
- Frequency response of 10-100,000 Hz, -0.5 dB, +0.05 dB Online.
- Frequency response of 20-20,000 Hz, -0.5 dB, +0.3 dB in Phono.
- Dimensions: 430 x 73 x 347 mm (W x H x D).
- Weight: 6.8 kg.
