Dedicated, like the emblematic MC Anna, to the extraordinary Russian soprano Anna Netrebko, the MC Anna Diamond represents the highest expression of Ortofon 's know-how in moving coil cartridges. There are many outstanding design elements of this exceptional transducer, the first being a body made of titanium using the exclusive "Selective Laser Melting" technique. The second notable engineering element of the MC Anna Diamond is the application of a high-performance iron-cobalt alloy to selected parts of the magnetic motor, coupled with a sophisticated Wide Range Damping system that It helps to completely eliminate unwanted resonances.
Another aspect worth mentioning about the new Ortofon is the use of the aforementioned Replicant 100 diamond reading tip exclusive to the Danish brand, extremely thin and light, while also having an extraordinarily large contact surface, which provides an ability to unprecedented tracking (that is, exploration of the vinyl groove). On the other hand, highlight the use of an exclusive thermoplastic elastomer to protect the coil windings, which also contributes to increasing the overall damping level of the assembly. Finally, the use of a diamond cantilever allows MC Anna Diamond to establish a before and after in the field of analog reading to the point of redefining what is possible in terms of reproduction of micro-details, subtleties and depth.
Characteristics:
- Absolute reference moving coil (MC) capsule.
- Titanium body manufactured layer by layer using Selective Laser Fusion.
- Cantilever built entirely in diamond.
- Ortofon 's exclusive Replicant 100 diamond reader tip.
- Field Stabilizing Element (FSE).
- Output voltage of 0.2 mV at 1 kHz and 5 cm/s.
- Frequency response: 20 - 20,000 Hz, +/-1.5 dB.
- Recommended Load Impedance: MC/ >10 Ohm.
- Tracking Ability: 80 um (at 315 Hz).
- Dynamic Compliance: 9 um/mN.
- Recommended Support Force: 2.4g.
- For reading arms of moderate and high mass.
- Weight: 16g.
