A distinguished 2-way/2-speaker bass-reflex monitor for shelf mounting or dedicated stands, which stands out first of all for incorporating the revolutionary “True Ribbon” tweeter, the result of exhaustive four-year work by the team. of QUAD engineering, in order to take the reproduction of the subtleties that constitute the soul of music even further.
This transducer is complemented by a high-performance “midwoofer” which, again, is the direct consequence of several years of research, development, evaluation and continuous improvements, highlighting the use, in the corresponding cone, of a new composition based on fibers. and baptized with the appropriate name “Reveal”. Refined for seamless integration with the aforementioned “True Ribbon”, this cone has been selected for its rigidity and excellent damping properties.
Together with an innovative peripheral rubber suspension custom-developed to facilitate large displacements without distortion, and a high-power motor, it allows you to obtain perfectly articulated mids and precise, fast and deep bass.
Let us finally point out that the management of the Revela 1 transducers is entrusted to a phase-compensated Linkwitz-Riley frequency divider filter, whose final configuration has been determined by combining the most advanced computer-aided design techniques with hundreds of hours of critical listening .
Characteristics:
- Monitor with very high performance and exceptional quality/price ratio.
- 2-way/2-speaker bass-reflex configuration
- “Midwoofer” with a new generation 165 mm fiber cone.
- QUAD Exclusive 27 x 60mm “True Ribbon” Ribbon Tweeter
- Frequency divider filter with phase-compensated Linkwitz-Riley topology.
- Multilayer panel enclosure with internal reinforcements finished by hand.
- Rear-emitting bass-reflex port.
- Custom made floor stand Revela Stand available optionally.
- Frequency response of 54-24,000 Hz, +/-3 dB.
- Sensitivity of 86 dB/W/m.
- Nominal impedance of 6 ohms (minimum of 4.1 ohms).
- Power of the associated amplifier between 20 and 120 W continuous.
- Dimensions: 246 x 395 x 386 mm (W x H x D).
- Weight: 24.6 kg.
Price per pair.
